Things used in this project

Hardware components:
Microsoft Lumia 950XL
You can use also other windows 10 devices
×1
Microsoft Xbox One Controller (bluetooth)
×1
Pi 3 02
Raspberry Pi 3 Model B
Also a raspberry pi 2 is compatible with this project
×1
Drone Frame
This frame has the power distribution board built in
×1
AfroFlight Naze32 Rev6 Flight Controller
×1
Hobby King 30A ESC 3A UBEC
×4
Turnigy D3530/14 1100KV Brushless Outrunner Motor
×4
Hobbyking Slowfly Propeller 10x4.5 Blue (CW/CCW) (4pcs)
×1
Turnigy 3300mAh 3S 30C Lipo Pack
×1
Gold Plated Spring Connector 3.5mm
You need only 12 female connector to connect ESCs to Motor
×2
HXT 4mm Gold Connector
You need just one of this to connect the battery to the power distribution board
×1
Mini Ublox NEO-M8N GPS for Naze32 / Flip32
GPS module for Naze 32 flight controller
×1
51gzz5eu9pl. sx425
Ultrasonic Sensor - HC-SR04 (Generic)
×1
Microsoft Lifecam HD-3000
×1
Vodafone K5150 4G/LTE USB
4G/LTE modem for web socket connection - Compatible with Windows 10 IoT core
×1
Wireless 300N USB 2.0 Dongle
This wifi dongle is compatible with Windows 10 IoT core, i choose this one because it has the removible external antenna
×1
Micro USB data cable
This short cable is required to connect RPi to the flight controller
×1
Software apps and online services:
10
Microsoft Windows 10 IoT Core
W9gt7hzo
Microsoft Azure
Hand tools and fabrication machines:
09507 01
Soldering iron (generic)

Schematics

The Idea 1.0
2 3hu0kfwvpc
The Idea 2.0
3 frtu7xziz3
RPi and fligh controller connection
1 kixi4u4imk
